When to Use MLP, CNN, and RNN Neural Networks

Author: Jason Brownlee

What neural network is appropriate for your predictive modeling problem?

It can be difficult for a beginner to the field of deep learning to know what type of network to use. There are so many types of networks to choose from and new methods being published and discussed every day.

To make things worse, most neural networks are flexible enough that they work (make a prediction) even when used with the wrong type of data or prediction problem.

In this post, you will discover the suggested use for the three main classes of artificial neural networks.

After reading this post, you will know:

Which types of neural networks to focus on when working on a predictive modeling problem.
When to use, not use, and possible try using an MLP, CNN, and RNN on a project.
To consider the use of hybrid models and to have a clear idea of your project goals before selecting a model.

Let’s get started.

When to Use MLP, CNN, and RNN Neural Networks
Photo by PRODAVID S. FERRY III,DDS, some rights reserved.

Overview

This post is divided into five sections; they are:

What Neural Networks to Focus on?
When to Use Multilayer Perceptrons?
When to Use Convolutional Neural Networks?
When to Use Recurrent Neural Networks?
Hybrid Network Models

What Neural Networks to Focus on?

Deep learning is the application of artificial neural networks using modern hardware.

It allows the development, training, and use of neural networks that are much larger (more layers) than was previously thought possible.

There are thousands of types of specific neural networks proposed by researchers as modifications or tweaks to existing models. Sometimes wholly new approaches.

As a practitioner, I recommend waiting until a model emerges as generally applicable. It is hard to tease out the signal of what works well generally from the noise of the vast number of publications released daily or weekly.

There are three classes of artificial neural networks that I recommend that you focus on in general. They are:

Multilayer Perceptrons (MLPs)
Convolutional Neural Networks (CNNs)
Recurrent Neural Networks (RNNs)

These three classes of networks provide a lot of flexibility and have proven themselves over decades to be useful and reliable in a wide range of problems. They also have many subtypes to help specialize them to the quirks of different framings of prediction problems and different datasets.

Now that we know what networks to focus on, let’s look at when we can use each class of neural network.

When to Use Multilayer Perceptrons?

Multilayer Perceptrons, or MLPs for short, are the classical type of neural network.

They are comprised of one or more layers of neurons. Data is fed to the input layer, there may be one or more hidden layers providing levels of abstraction, and predictions are made on the output layer, also called the visible layer.

For more details on the MLP, see the post:

Crash Course On Multi-Layer Perceptron Neural Networks

Model of a Simple Network

MLPs are suitable for classification prediction problems where inputs are assigned a class or label.

They are also suitable for regression prediction problems where a real-valued quantity is predicted given a set of inputs. Data is often provided in a tabular format, such as you would see in a CSV file or a spreadsheet.

Use MLPs For:

Tabular datasets
Classification prediction problems
Regression prediction problems

They are very flexible and can be used generally to learn a mapping from inputs to outputs.

This flexibility allows them to be applied to other types of data. For example, the pixels of an image can be reduced down to one long row of data and fed into a MLP. The words of a document can also be reduced to one long row of data and fed to a MLP. Even the lag observations for a time series prediction problem can be reduced to a long row of data and fed to a MLP.

As such, if your data is in a form other than a tabular dataset, such as an image, document, or time series, I would recommend at least testing an MLP on your problem. The results can be used as a baseline point of comparison to confirm that other models that may appear better suited add value.

Try MLPs On:

Image data
Text Data
Time series data
Other types of data

When to Use Convolutional Neural Networks?

Convolutional Neural Networks, or CNNs, were designed to map image data to an output variable.

They have proven so effective that they are the go-to method for any type of prediction problem involving image data as an input.

For more details on CNNs, see the post:

Crash Course in Convolutional Neural Networks for Machine Learning

The benefit of using CNNs is their ability to develop an internal representation of a two-dimensional image. This allows the model to learn position and scale in variant structures in the data, which is important when working with images.

Use CNNs For:

Image data
Classification prediction problems
Regression prediction problems

More generally, CNNs work well with data that has a spatial relationship.

The CNN input is traditionally two-dimensional, a field or matrix, but can also be changed to be one-dimensional, allowing it to develop an internal representation of a one-dimensional sequence.

This allows the CNN to be used more generally on other types of data that has a spatial relationship. For example, there is an order relationship between words in a document of text. There is an ordered relationship in the time steps of a time series.

Although not specifically developed for non-image data, CNNs achieve state-of-the-art results on problems such as document classification used in sentiment analysis and related problems.

Try CNNs On:

Text data
Time series data
Sequence input data

When to Use Recurrent Neural Networks?

Recurrent Neural Networks, or RNNs, were designed to work with sequence prediction problems.

Sequence prediction problems come in many forms and are best described by the types of inputs and outputs supported.

Some examples of sequence prediction problems include:

One-to-Many: An observation as input mapped to a sequence with multiple steps as an output.
Many-to-One: A sequence of multiple steps as input mapped to class or quantity prediction.
Many-to-Many: A sequence of multiple steps as input mapped to a sequence with multiple steps as output.

The Many-to-Many problem is often referred to as sequence-to-sequence, or seq2seq for short.

For more details on the types of sequence prediction problems, see the post:

Gentle Introduction to Models for Sequence Prediction with Recurrent Neural Networks

Recurrent neural networks were traditionally difficult to train.

The Long Short-Term Memory, or LSTM, network is perhaps the most successful RNN because it overcomes the problems of training a recurrent network and in turn has been used on a wide range of applications.

For more details on RNNs, see the post:

Crash Course in Recurrent Neural Networks for Deep Learning

RNNs in general and LSTMs in particular have received the most success when working with sequences of words and paragraphs, generally called natural language processing.

This includes both sequences of text and sequences of spoken language represented as a time series. They are also used as generative models that require a sequence output, not only with text, but on applications such as generating handwriting.

Use RNNs For:

Text data
Speech data
Classification prediction problems
Regression prediction problems
Generative models

Recurrent neural networks are not appropriate for tabular datasets as you would see in a CSV file or spreadsheet. They are also not appropriate for image data input.

Don’t Use RNNs For:

Tabular data
Image data

RNNs and LSTMs have been tested on time series forecasting problems, but the results have been poor, to say the least. Autoregression methods, even linear methods often perform much better. LSTMs are often outperformed by simple MLPs applied on the same data.

For more on this topic, see the post:

On the Suitability of Long Short-Term Memory Networks for Time Series Forecasting

Nevertheless, it remains an active area.

Perhaps Try RNNs on:

Time series data

Hybrid Network Models

A CNN or RNN model is rarely used alone.

These types of networks are used as layers in a broader model that also has one or more MLP layers. Technically, these are a hybrid type of neural network architecture.

Perhaps the most interesting work comes from the mixing of the different types of networks together into hybrid models.

For example, consider a model that uses a stack of layers with a CNN on the input, LSTM in the middle, and MLP at the output. A model like this can read a sequence of image inputs, such as a video, and generate a prediction. This is called a CNN LSTM architecture.

The network types can also be stacked in specific architectures to unlock new capabilities, such as the reusable image recognition models that use very deep CNN and MLP networks that can be added to a new LSTM model and used for captioning photos. Also, the encoder-decoder LSTM networks that can be used to have input and output sequences of differing lengths.

It is important to think clearly about what you and your stakeholders require from the project first, then seek out a network architecture (or develop one) that meets your specific project needs.

For a good framework to help you think about your data and prediction problems, see the post:

How to Define Your Machine Learning Problem

Summary

In this post, you discovered the suggested use for the three main classes of artificial neural networks.

Specifically, you learned:

Which types of neural networks to focus on when working on a predictive modeling problem.
When to use, not use, and possible try using an MLP, CNN, and RNN on a project.
To consider the use of hybrid models and to have a clear idea of your project goals before selecting a model.

Do you have any questions?
Ask your questions in the comments below and I will do my best to answer.
